16 Ton Capacity Mobile Hydraulic Truck Crane High Load Moment For Construction

Hydraulic Truck Crane 16 Ton

Construction Mobile Hydraulic Truck Crane

High Load Moment 16 Ton Crane

Place of Origin:

Henan, China

Brand Name:

LIYUE

Request A Quote

16 Ton Capacity Mobile Hydraulic Truck Crane High Load Moment For Construction

Product Details

Feature:

TRUCK CRANE

Showroom Location:

Uzbekistan

Condition:

New

Application:

Construction

Rated Loading Capacity:

16000kg

Rated Lifting Moment:

480 KN.m

Max. Lifting Height:

34m

Span:

4800/ 2290-6290mm

Warranty:

1 Year

Hydraulic Cylinder Brand:

Liyuan

Hydraulic Pump Brand:

Liyuan

Hydraulic Valve Brand:

Liyuan

Engine Brand:

WEICHAI

UNIQUE SELLING POINT:

High Load Moment

Machinery Test Report:

Provided

Video Outgoing-inspection:

Provided

Marketing Type:

Ordinary Product

Warranty Of Core Components:

1 Year

Core Components:

Bearing

Weight (KG):

15800 Kg

Product Name:

High Quality Telescopic Boom 16Ton Crane Machine

Hydraulic Parts:

Telescopic Boom Mobile Crane Made

Brand:

OEM Service

Origin:

100% China

Capacity:

16 Ton Truck Crane

Boom Type:

Hydraulic Straight Arm

Chassis Brand:

DongFeng.FAW.Foton.Sino.JAC.IVECO.Shacman

Color:

Customer Requirements

Emission Standard:

Euro 1/2/3/4/5

Delivery Time:

Within 35 Days

Highlight:

Hydraulic Truck Crane 16 Ton

Construction Mobile Hydraulic Truck Crane

High Load Moment 16 Ton Crane

Payment & Shipping Terms

Price

$47,000.00/units 1-4 units

Stiff Boom Mobile Hydraulic Truck Crane 8 Ton Hoisting For Construction

Get Best Price

8 Ton Mini Mobile Truck Crane For Hydraulic Boom 3900/ 2240 - 4840mm Span

Get Best Price

6 Ton Construction Mobile Truck Crane 360 Degree Rotation With Hydraulic Parts

Get Best Price

Construction Hydraulic Pump Truck Crane 12 Ton With 4800 / 2290 - 6290mm Span

Get Best Price

+86 153 3382 6131

info@liyuemachinery.com

86-153-3382-6131

Contact Now

Product Description

16 Ton Capacity Truck Crane For Hydraulic Mobile Construction Machine

Product Description

Project		Unit	Value
Crane Dimension	Model	-	QY 16-5-34
	Dimensions (LWH)	mm	1126023303260
	Outrigger Longitudinal/ Horizontal Span	mm	4800/ 2290-6290
	Outriggers Quantity	piece	5
	Basic Boom Lifting Length	m	9.1-30.28
	Main Boom Elevation	º	3-80
Working Parameter	Boom Quantity	Section	5
	Hydraulic Tank Capacity	L	200
	Max. Total Lifting Capacity	KG	16000
	The Basic Boom Lifting Torque (Max.)	KN.m	480
	Max. Lifting Height	m	34
	Working Radius	m	3--22
	Max. Slewing Speed	r/ min	≤3
Dongfeng Chassis Parameter	Total Mass	kg	15800
	Front And Rear Axle Load	kg	4800/ 11000
	Drive Type	-	4x2 Left Hand Drive
	Emission Standard	-	Euro 3
	Tyre Size	-	8.25-16
	Front/ Rear Track	mm	1640/ 1650
	Engine Power	HP	160
	Wheel Base	mm	4300
Travelling Parameter	Max. Travel Speed	Km/ h	75
	Max. Gradeability	%	17
	Min. Turning Diameter	m	18
	Approach Angle/ Departure Angle	º	21/ 16
	Fuel Consumption of 100km	L	28
	Min. Ground Clearance	mm	260
