3.2 Ton Straight Arm Mobile Truck Mounted Crane With 7.6 T.M Rated Lifting Moment

3.2 Ton Truck Mounted Crane

Straight Arm Mobile Truck Mounted Crane

Mobile Truck Crane 3.2 Ton

Place of Origin:

Henan, China

Brand Name:

LIYUE

Request A Quote

3.2 Ton Straight Arm Mobile Truck Mounted Crane With 7.6 T.M Rated Lifting Moment

Product Details

Feature:

TRUCK CRANE

Showroom Location:

Indonesia

Condition:

New

Application:

Construction

Rated Loading Capacity:

3 Ton

Rated Lifting Moment:

7.6 T.M

Max. Lifting Height:

11m

Span:

4.6m

Warranty:

1 Year

Hydraulic Cylinder Brand:

MOOG

Hydraulic Pump Brand:

Changjiang

Hydraulic Valve Brand:

Liyuan

Engine Brand:

YUNNEI

UNIQUE SELLING POINT:

High Operating Efficiency

Machinery Test Report:

Provided

Video Outgoing-inspection:

Provided

Marketing Type:

New Product 2020

Warranty Of Core Components:

1 Year

Core Components:

Bearing, Gearbox, Engine

Weight (KG):

1500 Kg

Product Name:

Truck Mounted Crane

Crane Type:

Truck Crane Mobile Crane Hydraulic Crane

Hydraulic Parts:

Famous Brand Hydraulic Parts

Capacity:

1-3 Ton Truck Crane

Boom Type:

Hydraulic Straight Arm

Color:

Customer Requirements

Usage:

Construction Lifting

Rotation Angle:

360 Degree

Installation Space:

900mm

High Quality:

Mobile Crane Lifting Capacity

Highlight:

3.2 Ton Truck Mounted Crane

Straight Arm Mobile Truck Mounted Crane

Mobile Truck Crane 3.2 Ton

Payment & Shipping Terms

Price

$7,000.00/units 1-4 units

Packaging Details

Nude packing

Supply Ability

3000 Unit/Units per Year

Telescopic Boom Mobile Lorry Crane 5 Ton MOOG Hydraulic Cylinder For Heavy Loads

Get Best Price

Mobile Telescopic Arm Lorry Crane 6.3 Ton For Industrial Construction

Get Best Price

3.2 Ton Straight Arm Mobile Truck Mounted Crane With 7.6 T.M Rated Lifting Moment

Get Best Price

Stiff Loader Mobile Lorry Crane 8 Ton Straight Arm With Max. Lifting Height Of 15.2m

Get Best Price

+86 153 3382 6131

info@liyuemachinery.com

86-153-3382-6131

Contact Now

Product Description

3.2 Ton Straight Arm Mobile Truck Mounted Crane With 7.6 T.M Rated Lifting Moment

Product Description

NOTE: The price is only for crane part.

Project		Unit	Value
Crane Dimension	Crane Model	-	SQ 3.2T
	Max. Lifting Capacity	kg	3200
	Max. Lifting Height	m	9
	Working Radius/ Span	m	0.67-10
	Rotation Angle	º	360 Continious
	Boom Raising Angle Scope	º	0-75
	Boom Sections	Piece	3
	Outrigger Quantity	Piece	2
	Outrigger Span (Fully Extended)	mm	1898-3329
	Crane Weight	kg	1290
	Hydraulic Tank Capacity	L	35
	Max. Flow Rate of Hydraulic Oil System	L/min	25
	Hydraulic System Rated Pressure	Mpa	21
	Installation Space	mm	850
Working Parameter	The Basic Boom Length	m	3.38-11.0
	Max. Lifting Torque	T.m	6.8
	Max. Slewing Speed	r/ min	2.5

Product Process

Famous Brand Hydraulic Parts for our Truck Crane

3.2 Ton Straight Arm Mobile Truck Mounted Crane With 7.6 T.M Rated Lifting Moment 4

Prodution Progress

3.2 Ton Straight Arm Mobile Truck Mounted Crane With 7.6 T.M Rated Lifting Moment 5

Packing & Shipping

3.2 Ton Straight Arm Mobile Truck Mounted Crane With 7.6 T.M Rated Lifting Moment 6

Client Visit

3.2 Ton Straight Arm Mobile Truck Mounted Crane With 7.6 T.M Rated Lifting Moment 7

3.2 Ton Straight Arm Mobile Truck Mounted Crane With 7.6 T.M Rated Lifting Moment 8

Certifications

3.2 Ton Straight Arm Mobile Truck Mounted Crane With 7.6 T.M Rated Lifting Moment 9

Optional Device

3.2 Ton Straight Arm Mobile Truck Mounted Crane With 7.6 T.M Rated Lifting Moment 10

Foreign Cases

3.2 Ton Straight Arm Mobile Truck Mounted Crane With 7.6 T.M Rated Lifting Moment 11
