6 Ton Straight Boom Hydraulic Truck Crane With Professional Construction Machinery

Professional Construction Machinery Truck Crane

Professional Construction Machinery Hydraulic Truck Crane

6 Ton Truck Crane

Place of Origin:

Henan, China

Brand Name:

LIYUE

Request A Quote

6 Ton Straight Boom Hydraulic Truck Crane With Professional Construction Machinery

Product Details

Feature:

TRUCK CRANE

Showroom Location:

Indonesia

Condition:

New

Application:

Construction

Rated Loading Capacity:

6 TON

Rated Lifting Moment:

180 KN.M

Max. Lifting Height:

26 M

Span:

3650/2190-4290 Mm

Warranty:

1 Year

Hydraulic Cylinder Brand:

MOOG

Hydraulic Pump Brand:

Changjiang

Hydraulic Valve Brand:

Liyuan

Engine Brand:

YUNNEI

UNIQUE SELLING POINT:

High Operating Efficiency

Machinery Test Report:

Provided

Video Outgoing-inspection:

Provided

Marketing Type:

Ordinary Product

Warranty Of Core Components:

3 Months

Core Components:

Pressure Vessel, Motor, Pump, Gearbox, Engine

Weight (KG):

8280 Kg

Product Name:

Truck Crane

Crane Type:

Truck Crane Mobile Crane Hydraulic Crane

Hydraulic Parts:

Famous Brand Hydraulic Parts

Capacity:

1-6 Ton Truck Crane

Boom Type:

Hydraulic Straight Arm

Color:

Customer Requirements

Usage:

Construction Lifting

Rotation Angle:

360 Degree

Keyword:

Crane Truck Mobile Truck Crane Sizes

High Quality:

Mobile Crane Lifting Capacity

Highlight:

Professional Construction Machinery Truck Crane

Professional Construction Machinery Hydraulic Truck Crane

6 Ton Truck Crane

Payment & Shipping Terms

Price

$13,900.00/units 1-2 units

Packaging Details

Nude packing

Supply Ability

3000 Unit/Units per Year

China's Top Brand 12 Ton Telescopic Boom Cargo Mobile Truck Crane for Sale

Get Best Price

Dongfeng New 12 Ton Truck Crane China Construction Mobile Crane Price for Sale

Get Best Price

Construction Engineering Crane Telescopic Boom Crane Hydraulic 12 Tons Mobile Crane

Get Best Price

Lifting Crane Equipment 12 Tons NEW High Lift Mobile Crane

Get Best Price

+86 153 3382 6131

info@liyuemachinery.com

86-153-3382-6131

Contact Now

Product Description

6ton Small Construction Truck Crane

Product Description

Project		Unit	Value
Crane Dimension	Model	-	QY 6-5-24
	Dimensions (LWH)	mm	895021903000
	Outrigger Longitudinal/ Horizontal Span	mm	3650/ 2190-4290
	Outriggers Quantity	piece	5
	Basic Boom Lifting Length	m	7.35-25.35
	Main Boom Elevation	º	3-80
Working Parameter	Boom Quantity	Section	5
	Hydraulic Tank Capacity	L	140
	Max. Total Lifting Capacity	KG	6000
	The Basic Boom Lifting Torque (Max.)	KN.m	180
	Max. Lifting Height	m	24
	Working Radius	m	3--16
	Max. Slewing Speed	r/ min	≤3
Dongfeng Chassis Parameter	Total Mass	kg	8280
	Front And Rear Axle Load	kg	2680/ 5600
	Drive Type	-	4*2 Left/ Right Hand Drive
	Emission Standard	-	Euro 3
	Tyre Size	-	7.50-16LT
	Front/ Rear Track	mm	1690/ 1650
	Engine Power	HP	102
	Wheel Base	mm	3360
Travelling Parameter	Max. Travel Speed	Km/ h	75
	Max. Gradeability	%	30
	Min. Turning Diameter	m	14
	Approach Angle/ Departure Angle	º	20/ 12
	Fuel Consumption of 100km	L	16
	Min. Ground Clearance	mm	260

Product Process

Famous Brand Hydraulic Parts for our Truck Crane

6 Ton Straight Boom Hydraulic Truck Crane With Professional Construction Machinery 4

Prodution Progress

6 Ton Straight Boom Hydraulic Truck Crane With Professional Construction Machinery 5

Packing & Shipping

6 Ton Straight Boom Hydraulic Truck Crane With Professional Construction Machinery 6

Client Visit

6 Ton Straight Boom Hydraulic Truck Crane With Professional Construction Machinery 7

6 Ton Straight Boom Hydraulic Truck Crane With Professional Construction Machinery 8

Certifications

6 Ton Straight Boom Hydraulic Truck Crane With Professional Construction Machinery 9

Optional Device

6 Ton Straight Boom Hydraulic Truck Crane With Professional Construction Machinery 10

Foreign Cases

6 Ton Straight Boom Hydraulic Truck Crane With Professional Construction Machinery 11
