Truck Mounted Mini Jib Crane Hydraulic Straight Arm 12 Ton For Construction

Truck Mounted Mini Jib Crane

Hydraulic Straight Arm Mini Jib Crane

Mini 12 Ton Crane

Place of Origin:

Henan, China

Brand Name:

LIYUE

Request A Quote

Truck Mounted Mini Jib Crane Hydraulic Straight Arm 12 Ton For Construction

Product Details

Feature:

TRUCK CRANE

Showroom Location:

Indonesia

Condition:

New

Application:

Construction

Rated Loading Capacity:

12 Ton

Rated Lifting Moment:

5.15-15 T.M

Max. Lifting Height:

17.2 M

Span:

2270-5270 Mm

Warranty:

1 Year

Hydraulic Cylinder Brand:

MOOG

Hydraulic Pump Brand:

Changjiang

Hydraulic Valve Brand:

Liyuan

Engine Brand:

YUNNEI

UNIQUE SELLING POINT:

High Operating Efficiency

Machinery Test Report:

Provided

Video Outgoing-inspection:

Provided

Marketing Type:

Ordinary Product

Warranty Of Core Components:

1 Year

Core Components:

Bearing, Pump

Weight (KG):

4316 Kg

Product Name:

Truck Mounted Crane

Crane Type:

Truck Crane Mobile Crane Hydraulic Crane

Hydraulic Parts:

Famous Brand Hydraulic Parts

Capacity:

12 Ton Truck Crane

Boom Type:

Hydraulic Straight Arm

Color:

Customer Requirements

Usage:

Construction Lifting

Rotation Angle:

360 Degree

Installation Space:

1300 Mm

High Quality:

Mobile Crane Lifting Capacity

Highlight:

Truck Mounted Mini Jib Crane

Hydraulic Straight Arm Mini Jib Crane

Mini 12 Ton Crane

Payment & Shipping Terms

Price

$21,400.00/units 1-2 units

Packaging Details

Nude packing

Supply Ability

3000 Unit/Units per Year

Telescopic Boom Mini Jib Crane Customized 8 Ton Hydraulic Mobile Crane

Get Best Price

Construction Lifting Cranes 5 Ton And 8 Ton Mini Manipulator Crane

Get Best Price

10 Ton Stiff Arm Mobile Truck Mounted Crane With 25 T.M Rated Lifting Moment

Get Best Price

Truck Mounted Mini Jib Crane Hydraulic Straight Arm 12 Ton For Construction

Get Best Price

+86 153 3382 6131

info@liyuemachinery.com

86-153-3382-6131

Contact Now

Product Description

12 Ton Hydraulic Straight Arm Truck Mounted Crane And Best For Customer Requirements

NOTE: The price is for crane part only.

SPECIFICATIONS FOR 12 TON CRANE TRUCK
Crane Dimension	Model	-	SQ 12T
	Max. Lifting Capacity	kg	12000
	Max. Lifting Height	m	17.2
	Working Radius/ Span	m	2.5- 13.5
	Rotation Angle	º	360
	Boom Elevation	º	3-75
	Boom Sections	Pcs	4
	Outrigger Span (Fully Extended)	mm	2270-5270
	Crane Weight	kg	4316
	Hydraulic Tank Capacity	L	160
	Max. Flow Rate of Hydraulic Oil System	L/min	63
	Hydraulic System Rated Pressure	Mpa	26
	Installation Space	mm	1300
Working Parameter	The Basic Boom Length	m	5.15-15
	Max. Lifting Torque	T.m	30
	Max. Slewing Speed	r/ min	2
