Hydraulic Compact 4 Ton Small Stiff Arm Mobile Lorry Crane for Construction Lifting

Hydraulic Compact 4 Ton Small Stiff Arm Mobile Lorry Crane for Construction Lifting

4 Ton Mobile Lorry Crane

Construction Lifting Mobile Lorry Crane

Small Stiff Arm Mobile Lorry Crane

Place of Origin:

Henan, China

Brand Name:

LIYUE

Contact Us
Request A Quote
Hydraulic Compact 4 Ton Small Stiff Arm Mobile Lorry Crane for Construction Lifting Hydraulic Compact 4 Ton Small Stiff Arm Mobile Lorry Crane for Construction Lifting Hydraulic Compact 4 Ton Small Stiff Arm Mobile Lorry Crane for Construction Lifting Hydraulic Compact 4 Ton Small Stiff Arm Mobile Lorry Crane for Construction Lifting Hydraulic Compact 4 Ton Small Stiff Arm Mobile Lorry Crane for Construction Lifting Hydraulic Compact 4 Ton Small Stiff Arm Mobile Lorry Crane for Construction Lifting
Product Details
Feature:
TRUCK CRANE
Showroom Location:
Indonesia
Condition:
New
Application:
Construction
Rated Loading Capacity:
4 Ton
Rated Lifting Moment:
6.8 T.M
Max. Lifting Height:
11.5 M
Span:
1989-3329 Mm
Warranty:
1 Year
Hydraulic Cylinder Brand:
MOOG
Hydraulic Pump Brand:
Changjiang
Hydraulic Valve Brand:
Liyuan
Engine Brand:
YUNNEI
UNIQUE SELLING POINT:
High Operating Efficiency
Machinery Test Report:
Provided
Video Outgoing-inspection:
Provided
Marketing Type:
Ordinary Product
Warranty Of Core Components:
1 Year
Core Components:
Bearing, Pump
Weight (KG):
1271 Kg
Product Name:
Truck Mounted Crane
Crane Type:
Truck Crane Mobile Crane Hydraulic Crane
Hydraulic Parts:
Famous Brand Hydraulic Parts
Capacity:
4 Ton Truck Crane
Boom Type:
Hydraulic Straight Arm
Color:
Customer Requirements
Usage:
Construction Lifting
Rotation Angle:
360 Degree
Installation Space:
850 Mm
High Quality:
Mobile Crane Lifting Capacity
Highlight:

4 Ton Mobile Lorry Crane

,

Construction Lifting Mobile Lorry Crane

,

Small Stiff Arm Mobile Lorry Crane

Payment & Shipping Terms
Price
$8,100.00/units 1-2 units
Packaging Details
Nude packing
Supply Ability
3000 Unit/Units per Year
RELATED PRODUCTS
Good price Dongfeng 5 Ton Telescopic Boom Truck Crane Hydraulic Mobile Lorry Crane For Special Transportation online Video

Dongfeng 5 Ton Telescopic Boom Truck Crane Hydraulic Mobile Lorry Crane For Special Transportation

Get Best Price
Good price Customizable 8 Tons Hydraulic Truck Mounted Crane Telescopic Boom Truck Mounted Cranes Mini Crane online Video

Customizable 8 Tons Hydraulic Truck Mounted Crane Telescopic Boom Truck Mounted Cranes Mini Crane

Get Best Price
Good price 4 Ton Hydraulic Cargo Truck Crane Hydraulic Lorry Crane Mini Truck Mounted Crane online Video

4 Ton Hydraulic Cargo Truck Crane Hydraulic Lorry Crane Mini Truck Mounted Crane

Get Best Price
Good price 6.3 Ton Hydraulic Cranes Truck Mounted Crane Knuckle 4X2 Wheel Crane Truck online Video

6.3 Ton Hydraulic Cranes Truck Mounted Crane Knuckle 4X2 Wheel Crane Truck

Get Best Price
Contact Us
+86 153 3382 6131
info@liyuemachinery.com
86-153-3382-6131
Contact Now
Product Description

                                    Dongfeng 4 Tons Truck Mounted Crane

Product Description
NOTE: The price is only for crane part.
Hydraulic Compact 4 Ton Small Stiff Arm Mobile Lorry Crane for Construction Lifting 0

Project

Unit

Value

Crane Dimension

Crane Model

-

SQ 4T

Max. Lifting Capacity

kg

4000

Max. Lifting Height

m

11.5

Working Radius/ Span

m

2.1-7.93

Rotation Angle

º

360

Boom Raising Angle Scope

º

0-75

Boom Sections

Piece

3

Outrigger Quantity

Piece

2

Outrigger Span (Fully Extended)

mm

1989-3329

Crane Weight

kg

1271

Hydraulic Tank Capacity

L

30

Max. Flow Rate of Hydraulic Oil System

L/min

25

Hydraulic System Rated Pressure

Mpa

20

Installation Space

mm

850

Working Parameter

The Basic Boom Length

m

3.3-11.5

Max. Lifting Torque

T.m

6.8

Max. Slewing Speed

r/ min

2
 Hydraulic Compact 4 Ton Small Stiff Arm Mobile Lorry Crane for Construction Lifting 1
Hydraulic Compact 4 Ton Small Stiff Arm Mobile Lorry Crane for Construction Lifting 2
Hydraulic Compact 4 Ton Small Stiff Arm Mobile Lorry Crane for Construction Lifting 3
Product Description



Product Process

                               Famous Brand Hydraulic Parts for our Truck Crane



Hydraulic Compact 4 Ton Small Stiff Arm Mobile Lorry Crane for Construction Lifting 4



                                                            Prodution Progress



Hydraulic Compact 4 Ton Small Stiff Arm Mobile Lorry Crane for Construction Lifting 5

Packing & Shipping

Hydraulic Compact 4 Ton Small Stiff Arm Mobile Lorry Crane for Construction Lifting 6

Client Visit

Hydraulic Compact 4 Ton Small Stiff Arm Mobile Lorry Crane for Construction Lifting 7







Hydraulic Compact 4 Ton Small Stiff Arm Mobile Lorry Crane for Construction Lifting 8



Certifications

Hydraulic Compact 4 Ton Small Stiff Arm Mobile Lorry Crane for Construction Lifting 9



Optional Device

Hydraulic Compact 4 Ton Small Stiff Arm Mobile Lorry Crane for Construction Lifting 10

Foreign Cases

Hydraulic Compact 4 Ton Small Stiff Arm Mobile Lorry Crane for Construction Lifting 11

Related Products

Hydraulic Compact 4 Ton Small Stiff Arm Mobile Lorry Crane for Construction Lifting 12

customer evaluation

Hydraulic Compact 4 Ton Small Stiff Arm Mobile Lorry Crane for Construction Lifting 13
