Truck Crane Mobile Crane Hydraulic Crane 12 Ton Capacity for Industrial Applications

Truck Crane Mobile Crane Hydraulic Crane 12 Ton Capacity for Industrial Applications

Mobile Truck Crane

12 Ton Truck Crane

Industrial Applications Truck Crane

Place of Origin:

Henan, China

Brand Name:

LIYUE

Contact Us
Request A Quote
Truck Crane Mobile Crane Hydraulic Crane 12 Ton Capacity for Industrial Applications Truck Crane Mobile Crane Hydraulic Crane 12 Ton Capacity for Industrial Applications Truck Crane Mobile Crane Hydraulic Crane 12 Ton Capacity for Industrial Applications Truck Crane Mobile Crane Hydraulic Crane 12 Ton Capacity for Industrial Applications Truck Crane Mobile Crane Hydraulic Crane 12 Ton Capacity for Industrial Applications Truck Crane Mobile Crane Hydraulic Crane 12 Ton Capacity for Industrial Applications
Product Details
Feature:
TRUCK CRANE
Showroom Location:
Indonesia
Condition:
New
Application:
Construction
Rated Loading Capacity:
12 Ton
Rated Lifting Moment:
5.15-15 T.M
Max. Lifting Height:
17.2 M
Span:
2270-5270 Mm
Warranty:
1 Year
Hydraulic Cylinder Brand:
MOOG
Hydraulic Pump Brand:
Changjiang
Hydraulic Valve Brand:
Liyuan
Engine Brand:
YUNNEI
UNIQUE SELLING POINT:
High Operating Efficiency
Machinery Test Report:
Provided
Video Outgoing-inspection:
Provided
Marketing Type:
Ordinary Product
Warranty Of Core Components:
1 Year
Core Components:
Bearing, Pump
Weight (KG):
4316 Kg
Product Name:
Truck Mounted Crane
Crane Type:
Truck Crane Mobile Crane Hydraulic Crane
Hydraulic Parts:
Famous Brand Hydraulic Parts
Capacity:
12 Ton Truck Crane
Boom Type:
Hydraulic Straight Arm
Color:
Customer Requirements
Usage:
Construction Lifting
Rotation Angle:
360 Degree
Installation Space:
1300 Mm
High Quality:
Mobile Crane Lifting Capacity
Highlight:

Mobile Truck Crane

,

12 Ton Truck Crane

,

Industrial Applications Truck Crane

Payment & Shipping Terms
Price
$21,400.00/units 1-2 units
Packaging Details
Nude packing
Supply Ability
3000 Unit/Units per Year
RELATED PRODUCTS
Good price Dongfeng 5 Ton Telescopic Boom Truck Crane Hydraulic Mobile Lorry Crane For Special Transportation online Video

Dongfeng 5 Ton Telescopic Boom Truck Crane Hydraulic Mobile Lorry Crane For Special Transportation

Get Best Price
Good price Customizable 8 Tons Hydraulic Truck Mounted Crane Telescopic Boom Truck Mounted Cranes Mini Crane online Video

Customizable 8 Tons Hydraulic Truck Mounted Crane Telescopic Boom Truck Mounted Cranes Mini Crane

Get Best Price
Good price 4 Ton Hydraulic Cargo Truck Crane Hydraulic Lorry Crane Mini Truck Mounted Crane online Video

4 Ton Hydraulic Cargo Truck Crane Hydraulic Lorry Crane Mini Truck Mounted Crane

Get Best Price
Good price 6.3 Ton Hydraulic Cranes Truck Mounted Crane Knuckle 4X2 Wheel Crane Truck online Video

6.3 Ton Hydraulic Cranes Truck Mounted Crane Knuckle 4X2 Wheel Crane Truck

Get Best Price
Contact Us
+86 153 3382 6131
info@liyuemachinery.com
86-153-3382-6131
Contact Now
Product Description

12ton Construction Telescopic Boom Truck Mounted Crane

NOTE: The price is for crane part only.
Truck Crane Mobile Crane Hydraulic Crane 12 Ton Capacity for Industrial Applications 0
SPECIFICATIONS FOR 12 TON CRANE TRUCK









Crane Dimension
Model
-
SQ 12T
Max. Lifting Capacity
kg
12000
Max. Lifting Height
m
17.2
Working Radius/ Span
m
2.5- 13.5
Rotation Angle
º
360
Boom Elevation
º
3-75
Boom Sections
Pcs
4
Outrigger Span (Fully Extended)
mm
2270-5270
Crane Weight
kg
4316
Hydraulic Tank Capacity
L
160
Max. Flow Rate of Hydraulic Oil System
L/min
63
Hydraulic System Rated Pressure
Mpa
26
Installation Space
mm
1300

Working Parameter
The Basic Boom Length
m
5.15-15
Max. Lifting Torque
T.m
30
Max. Slewing Speed
r/ min
2
Truck Crane Mobile Crane Hydraulic Crane 12 Ton Capacity for Industrial Applications 1

Product Show
Product Show
Truck Crane Mobile Crane Hydraulic Crane 12 Ton Capacity for Industrial Applications 2
Truck Crane Mobile Crane Hydraulic Crane 12 Ton Capacity for Industrial Applications 3
Truck Crane Mobile Crane Hydraulic Crane 12 Ton Capacity for Industrial Applications 4



Product Process

                               Famous Brand Hydraulic Parts for our Truck Crane



Truck Crane Mobile Crane Hydraulic Crane 12 Ton Capacity for Industrial Applications 5



                                                            Prodution Progress



Truck Crane Mobile Crane Hydraulic Crane 12 Ton Capacity for Industrial Applications 6

Packing & Shipping

Truck Crane Mobile Crane Hydraulic Crane 12 Ton Capacity for Industrial Applications 7

Client Visit

Truck Crane Mobile Crane Hydraulic Crane 12 Ton Capacity for Industrial Applications 8







Truck Crane Mobile Crane Hydraulic Crane 12 Ton Capacity for Industrial Applications 9



Certifications

Truck Crane Mobile Crane Hydraulic Crane 12 Ton Capacity for Industrial Applications 10



Optional Device

Truck Crane Mobile Crane Hydraulic Crane 12 Ton Capacity for Industrial Applications 11

Foreign Cases

Truck Crane Mobile Crane Hydraulic Crane 12 Ton Capacity for Industrial Applications 12

Related Products

Truck Crane Mobile Crane Hydraulic Crane 12 Ton Capacity for Industrial Applications 13

customer evaluation

Truck Crane Mobile Crane Hydraulic Crane 12 Ton Capacity for Industrial Applications 14
