It is easy to shake when the boom of the truck crane is extended and retracted, especially when the boom is fully extended or the luffing up reaches the highest position and the boom is retracted or the luffing down is performed. Several reasons and solutions for the shaking of crane boom when it is retracted. The damping hole of balance valve is blocked. Troubleshooting: Disassemble and clean the balance valve and dredge the damping hole. There is low liquid level in the air hydraulic tank or leakage in the hydraulic circuit in the hydraulic cylinder. Troubleshooting: Find out the fault point of air in the hydraulic circuit, repair and exhaust the air in the hydraulic circuit. Excessive friction during boom extension. Troubleshooting: Replace the sliding block with wear exceeding the specified value, adjust the clearance between the boom and the sliding block to make it meet the specified value. Poor lubrication of boom slide block and slide way if the nylon slide block and slide way installed inside the boom are not well lubricated, it will also cause boom stretching and shaking. Troubleshooting: Regularly check the lubrication of sliding block and slideway, and apply lubricating grease in time to reduce the expansion resistance and prevent the boom.

10 Tons Truck Mounted Crane Introduction: LIYUE 10 tons truck crane can be mounted on Euro 5 Dongfeng/ Dayun/ WAW chassis. LIYUE 10 tons mobile crane max. Lifting height is 32m, with 2 types power, truck and electricity. Stable, safe, efficient, bilateral operation, the industry’s first king of 10 tons of crane performance, the leader of the Chinese domestic 10 tons of cranes. 10 Tons Truck Crane Advantage: ◆ Crane Boom: LIYUE 10 Tons truck crane adapted BS700 high-strength steel, strong rigidity, light weight boom is safe and reliable. the full arm height can reach 32 meters. ◆ Crane Beam: Box-type girders, strong bearing capacity, higher safety, and improved service life. ◆Liquid Motor: Jinjiang Lite multi-way valve hydraulic system, powerful power, lifting performance is greatly improved. ◆ Hydraulic Pump: Three pump confluence technology to improve stability, compound operation is more stable, and operation is more coordinated. ◆ Torque Limiter: Improve the safety of the whole truck crane, limit the overload protection, and warn when the action reaches the limit value to prevent the vehicle from tipping over. ◆ Mobile Counterweight: The crane counterweight can be moved, the use is flexible, the work efficiency is high, and the working range is wide. ◆ Crane Operating Cab: Beautiful streamline, spacious and bright field of view, built-in adjustable seat safe and comfortable ◆The plate cutting adopts laser cutting, which has high precision and beautiful appearance. The structural parts are painted by blasting and rusting to improve the life of the paint and make it more beautiful. Chinese LIYUE 10 Tons Truck Crane Main Specification: ◆ Forward/ Backward Extension (mm): 2205/95; Mobile crane wheelbase is 4200mm. ◆ Side protection material: Q235, bolt connection. ◆ Rear protective material: Q235. Connection mode is welding ◆ The size of rear protection plate section is 105 *50mm. ◆ The truck crane clearance is 430 mm. ◆ Adapted Shaanxi Fast Gearbox. ◆ The crane boom height is 5 sections * 32 meters. ◆ 1.3m external teeth slewing bearing. ◆ Crane vice hook adapted 6 tons hoisting, main hook 10 tons hoisting. With 5 outriggers. ◆ Crane Overall Size: 10180*2350*3300mm. ◆ Crane Engine: Weichai 132 HP, Euro 5 emission standard. ◆ Truck Crane Total Mass: 14055 kg.

  We have truck mounted crane 3.2- 25 tons stock: ⇒ 3.2T, Max. lifting height 11m, working range 2.1-7.5m, lifting 0.2T @ 7.5m. ⇒ 4T, Max. lifting height 11m, working range 2.5-7.5m, lifting 0.4T @ 7.5m. ⇒ 5T, Max. lifting height 12m, working range 2.5-8.5m, lifting 1T @ 8.5m. ⇒ 6.3T, Max. lifting height 13m, working range 2.5-11m, lifting 0.6T @ 11m. ⇒ 8T, Max. lifting height 18m, working range 2.5-15.1m, lifting 0.7T @ 15.1m. ⇒ 10T, Max. lifting height 18m, working range 2.5-15.1m, lifting 1T @ 15.1m. ⇒ 12T, Max. lifting height 21m, working range 2.5-15.1m, lifting 1.5T @ 15.1m. ⇒ 14T, Max. lifting height 21m, working range 2.5-15.5m, lifting 1.2T @ 15.5m. ⇒ 16T, Max. lifting height 21m, working range 2.5-15.5m, lifting 1.5T @ 15.1m. ⇒ 20T, Max. lifting height 23.56m, working range 2.5-18.5m, lifting 1T @ 18.5m.

Ms. Febri visited our factory on 2018-5-12 for long- term cooperation. We showed our advanced machines to her, and introduced the truck crane manufacturing progress and QC system. We answered a lot questions to her, so Mr. Febri can understand our goods very well. We signed a memorandum of cooperation. And booked 1 unit 10 tons truck crane with basket. The crane is for Indonesia PUPUK KALTIM, which is a national large petrochemical production enterprise. And we will have a training in Dec. 2018. After the trial order, they will book 5 sets again each year.
